INTERACTIVE UPS LA-VST
Technical datasheet
YouTube video
Interactive UPS LA-VST designed to offer basic electrical protection against power outages, surges, and voltage variations, incorporating AVR stabilization, USB communication, RJ11 protection, and management via ViewPower software to improve operational continuity and security for professional and home computer and electronic equipment.
✓Interactive UPS
✓Modified sine wave
✓Integrated AVR to ensure voltage stability
✓LED indicators
✓Off-mode charging
✓Cold start function
✓Microprocessor control ensures reliability
✓Auto restart while AC is recovering
✓Communication port: USB
✓RJ11 protection
✓ViewPower Software
✓Compact size
Interactive UPS VST Series
| Model | LA-VST-650 | LA-VST-850 |
|---|---|---|
| Capacity | 650 VA / 360 W | 850 VA / 480 W |
| INPUT | ||
| Voltage | 110/120 VAC or 220/230/240 VAC | |
| Voltage Range | 81-145 VAC / 162-290 VAC | |
| Frequency Range | 60/50 Hz (auto sensing) | |
| OUTPUT | ||
| AC Voltage Regulation (Batt. Mode) | ±10% | |
| Frequency Range (Batt. Mode) | 60 Hz or 50 Hz ±1 Hz | |
| Transfer Time | Typical 2-6 ms, 10ms max. | |
| Waveform (Batt. Mode) | Modified Sine Wave | |
| BATTERY | ||
| Type & Quantity | 12V / 7AH x 1 | 12V / 9AH x 1 |
| Runtime (1 PC @ 120W) | 10 min. | 15 min. |
| Recharge Time | 4 - 6 hours to 90% capacity | |
| INDICATORS | ||
| AC Mode | Green LED | |
| Battery Mode | Green LED flashes every 10 sec. | |
| Low Battery | Green LED flashes every second and Red LED on | |
| Fault | Red LED | |
| Overheating | Red LED flashes every 0.5 sec. | |
| PROTECTION | ||
| Full Protection | Overload, discharge, and overcharge protection | |
| ALARM | ||
| Battery Mode | Sounding every 10 seconds | |
| Low Battery | Sounding every second | |
| Overload | Sounding every 0.5 seconds | |
| Battery Replacement | Sounding every 2 seconds | |
| Fault | Continuously sounding | |
| INTERFACE | ||
| Output Connections | 2xSchuko | |
| Communication Ports | 1xUSB + 1xRJ11 | |
| PHYSICAL DATA | ||
| Dimensions DxWxH (mm) | 287 x 100 x 142 | |
| Net Weight (Kg) | 4.20 | 5.20 |
| WORKING ENVIRONMENT | ||
| Humidity | 0-90 % RH @ 0-40°C (non-condensing) | |
| Noise Level | Less than 40dB | |
| MANAGEMENT SOFTWARE | ||
| Supported OS | Supports Windows® 2000/2003/XP/Vista/2008/7, Linux, Unix and MAC | |
MODELS
Capacity
700
650 VA / 360 W
900
850 VA / 480 W
INPUT
Voltage
110/120 VAC or 220/230/240 VAC
Voltage Range
81-145 VAC / 162-290 VAC
Frequency Range
60/50 Hz (auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)
±10%
Frequency Range (Batt. Mode)
60 Hz or 50 Hz ±1 Hz
Transfer Time
Typical 2-6 ms, 10ms max.
Waveform (Batt. Mode)
Modified Sine Wave
BATTERY
Type Quantity
700
12V / 7AH x 1
900
12V / 9AH x 1
Runtime (1 PC @ 120W)
700
10 min.
900
15 min.
Recharge Time
4 - 6 hours to 90% capacity
INDICATORS
AC Mode
Green LED
Battery Mode
Green LED flashes every 10 sec.
Low Battery
Green LED flashes every second and Red LED on
Fault
Red LED
Overheating
Red LED flashes every 0.5 sec.
PROTECTION
Full Protection
Overload, discharge, and overcharge protection
ALARM
Battery Mode
Every 10 seconds
Low Battery
Every second
Overload
Every 0.5 seconds
Battery Replacement
Every 2 seconds
Fault
Continuous
INTERFACE
Output Connections
2xSchuko
Communication Ports
1xUSB + 1xRJ11
PHYSICAL DATA
Dimensions DxWxH (mm)
287 x 100 x 142
Net Weight (Kg)
700
4,20
900
5,20
WORKING ENVIRONMENT
Humidity
0-90 % RH @ 0-40°C (non-condensing)
Noise Level
Less than 40dB
MANAGEMENT SOFTWARE
Supported OS
Supports Windows® 2000/2003/XP/Vista/2008/7, Linux, Unix and MAC
